SFP-1000-SM13-40I
The SFP-1000-SM13-40I is an SFP transceiver with 1.25G.
The SFP-1000-SM13-40I is a 1.25G SFP transceiver reaching up to 40km over single-mode fibre via its LC connector. Rated for extended-temperature operation down to -40°C.
- Data Rate: 1.25G
- Wave Length: 1300/1310 nm
- Laser Type: Fabry-Perot
- Tx (dBm): -3 ~ 3 dBm
- RX (dBm): -3 ~ -24 dBm
- Voltage: 3.3V
- Transmission Range: 9/125µm, up to 40km
- Fibre Type (MMF / SMF): SMF
- DDM (Digital Diagnostics Monitoring): Yes
- Connector: LC
- Dimensions: 55.9mm (L) x 14.69mm (W) x 12.39mm (H)
- Operating Temperature: -40°C ~ 85°C (-40°F ~ 185°F)
- Storage Temperature: -40°C ~ 85°C (-40°F ~ 185°F)
- Humidity: 5 ~ 90% (non-condensing)
- MSA Compliant: Yes
- Certifications: IEC 825, EN60825-1, FDA 21 CFR 1040.10 and 1040.11
