DRL-48V240W1EN
The DRL-48V240W1EN is a Vivotek 48VDC DIN rail power supply rated 240W, for 90-264VAC input.
The DRL-48V240W1EN is a Vivotek power supply.
- Power Input Range: 90~264VAC
- Input Frequency Range: 47~63 Hz
- Input Current: 2.5 A typ.@115 VAC, 1.3A typ. @ 230VAC
- Output Voltage Adjustment Range: 43.2-52.8 VDC
- Output Current: 5A
- Output Power: 240W max
- Operating Temperature: -30°C to +70°C (-40°C Cold Start)
- Operating Humidity: 20 to 90% RH (Non-Condensing)
- Dimensions: 123.6 (H) x 40 (W) x 116.8 (D) mm
- Certifications: CE&UKCA/CB/TUV/UL/BIS/BSMI
