AW-IHB-1040
The AW-IHB-1040 is a 10 ports lite managed PoE switch with 300W.
The AW-IHB-1040 is a 10-port lite managed PoE switch with a 300W PoE power budget. 6KV surge protection guards the connected equipment, and rated for extended-temperature operation down to -40°C.
- Segment: Lite Managed PoE Switch
- Product Description: Industrial 2xGbE bt 90W + 6xGbE at 30W + 2xGbE SFP Lite Managed Switch
- PoE Port Ethernet: 8xGbE PoE
- Uplink Port Ethernet: 2xGbE SFP
- Total Ports: 10
- PoE Port: 8
- Max. PoE Output Power: Port 1-2 bt 90W; Port 3-8 at 30W
- PoE Power Budget: 300W
- PoE Standard: 802.3 af/at/bt
- PoE Pin Assignment: Port 1-4 bt: 4 pairs 1/2 (+), 3/6 (-) and 4/5 (+), 7/8 (-); Port 5-24 af/at: 2 pairs 1/2 (+), 3/6 (-)
- Surge Protection: 6KV
- Switching Bandwidth: 20 Gbps
- Buffer Memory: 1.5Mb
- Forwarding Rate: 14.88 Mpps
- MAC Address: 4K
- Jumbo Frames: 9216 Bytes
- Max. Power Consumption: 310W
- 802.1Q Tag-based VLAN: 4096 VLAN IDs
- Hardware Queues: 8
- Operating Temperature: -40°C ~ 75°C (-40°F ~ 167°F)
- Storage Temperature: -40°C ~ 85°C (-40°F ~ 185°F)
- Operating Humidity: 5% ~ 90% Non-Condensing
- Dimensions: 165 (W) x 123 (D) x 53.5 (H) mm
- Weight: 0.9 kg
- Power Input: 48-52VDC bt port up to 60W; 52-56VDC bt port up to 90W; Redundant power backup
- Types: CE, UKCA, FCC, VCCI, BSMI
