AW-IHB-0100
The AW-IHB-0100 is an industrial 90W bt PoE injector with 90W.
The AW-IHB-0100 injects up to 90W of PoE onto a single Ethernet link, powering a device with no PoE-capable switch required. Rated for extended-temperature operation down to -40°C.
- Gigabit Ethernet 10/100/1000Mbps (Data in): 1
- IEEE 802.3 10-BASE-T (Ethernet): Supported
- IEEE 802.3u 100-BASE-TX (Fast Ethernet): Supported
- IEEE 802.3ab 1000-BASE-T (Gigabit Ethernet): Supported
- IEEE 802.3 af/at/bt: Supported
- Number of PoE Output Port: 1
- Max. PoE Output Power: 90W
- IEEE PoE Standard: 802.3af/at/bt
- Over Current Protection: Supported
- Circuit Shorting Protection: Supported
- Total PoE Power Budget: 90W
- Power Pin Assignment: 1/2(-), 3/6(+), 4/5(+), 7/8(-)
- PoE PD Auto Detection: Supported
- Input Voltage Range: 48 ~ 56VDC for 30W 802.3af/at; 52 ~ 56VDC for 90W 802.3bt
- Output Voltage/Current: 54VDC/1.67A
- Electrostatic Discharge (ESD) Per IEC-61000-4-2: Contact discharge: ±6KV; Air discharge: ±8KV
- MTBF: 3, 216, 499 hours
- Dimensions: 94 (L) x 60 (W) x 28 (H) mm
- Weight: 0.2 kg
- Operating Temperature: -40°C ~ 75°C (-40°F ~ 167°F)
- Storage Temperature: -40°C ~ 85°C (-40°F ~ 185°F)
- Humidity: Operating: 5 ~ 90%; Storage: 5 ~ 90% (Non-condensing)
- Safety Certifications: CE, FCC, LVD EN62368-1, VCCI
- Warranty: 24 Months
