AW-GET-083A-120
The AW-GET-083A-120 is a 4xGE PoE + 2GE UTP + 2xGE SFP with 120W.
The AW-GET-083A-120 is an 8-port unmanaged PoE switch with a 120W PoE power budget. 6KV surge protection guards the connected equipment, rated for extended-temperature operation down to -40°C, and its housing is rated for direct outdoor installation.
- Segment: Unmanaged PoE Switch
- Product Description: 4xGE PoE + 2GE UTP + 2xGE SFP Outdoor PoE Switch
- PoE Port Ethernet: 4xGbE PoE
- Uplink Port Ethernet: 2xGbE RJ45 + 2xGbE SFP
- Total Ports: 8
- PoE Port: 4
- Max. PoE Output Power: 30W
- PoE Power Budget: 120W
- PoE Standard: 802.3 af/at
- PoE Pin Assignment: 1/2 (+), 3/6 (-)
- Surge Protection: 6KV
- Switching Bandwidth: 16G
- Buffer Memory: 1.5Mb
- Forwarding Rate: 11.904 Mpps
- MAC Address: 8K
- Jumbo Frames: 9216 Bytes
- Max. Power Consumption: 130W
- Operating Temperature: -40°C ~ 65°C (-40°F ~ 149°F)
- Storage Temperature: -40°C ~ 75°C (-40°F ~ 167°F)
- Operating Humidity: 10 ~ 90% (Non-condensing)
- Waterproof: IP67
- Vandal Proof: IK10
- Dimensions: 315.4 (W) x 245.8 (H) x 118 (D) mm
- Weight: 4.52 kg
- Power Input: 100V ~ 240V
- Frequency: 50 ~ 60 Hz
- Types: CB, CE, FCC, LVD, VCCI
