AU-004
The AU-004 is a Vivotek PoE network horn speaker with SIP support and a metal casing, drawing up to 15W.
The AU-004 is a Vivotek network audio accessory.
- Rated Impedance: 8 ohm
- PoE Standard: IEEE 802.3af
- Max. Power Consumption: 15W
- Frequency Ranges: 500-2KHZ +-10dB; 400-12KHZ +-20dB
- Max. Sound Pressure Level: 96dB
- Microphone: 50Hz-20kHz at 1Pa, 50cm distance, SPL 115dB at 1kHz
- SIP Support: RFC 3261
- Interface: WAN: RJ-45x1, 10/100Mbps Fast Ethernet port
- Supported Protocols: SIP, ONVIF, HTTP, IPv4, DHCP, RTSP, RTP, RTCP, TCP, UDP, ARP, FTP, TFTP, NFS, NTP
- Audio Codec: OPUS 48 kHz, MP3 44.1 kHz, G.722 ADPCM 16 kHz, G.711 PCMU 8 kHz, G.711 PCMA 8 kHz
- Security: Password protection, IP address filtering, Digest authentication, firewall
- Broadcasting: Supported
- Automatic Trigger Audio Clips: Supported
- Casing: Metal
- Power: PoE (Power over Ethernet, IEEE 802.3af ) or DC 12-24V
- Operating Temperature: -35°C ~ 60°C (-31°F ~ 140°F)
- Dimensions: 200 x 90 mm
- Weight: 1 kg
- Certifications: CE, FCC, VCCI, BSMI
